Applications

In determination of concentration of constituents in

• Clinical, Pharmaceutical, Food, Beverage & Water analysis
• Analytical & Agricultural chemistry
• Aquaculture and Agriculture soil testing
• Biological Samples
• Metallurgy

Specifications

PHOTOMETRIC :
Range	0 to 1.99 Abs
Repeatability	± 0.01 Abs
Stability	± 0.01 Abs in 8 hrs.

LIGHT SOURCE	Long life solid state light source
FILTER (8)	Peak transmission at 450, 470, 510, 520, 540, 570, 600 & 670 nm

SHUTTER	To prevent the detector from continuous exposure to light
DETECTOR	Photodiode
READOUT	2½ digit 7 segment LED display of 12.7mm height
POWER REQUIREMENT	230 V ± 10%, 50 Hz, 1 Max. 20 VA
PHYSICAL DIMENSIONS	Size (W x D x H) in mm Weight in kg.270 x 180 x 110 Approx.3
ACCESSORIES SUPPLIED With instruments	Matched test tubes
